TECHNICAL DATA
Antenna Connection TwistPort™ – Quick Locking Waveguide Port
Antenna Type Horn
Materials UV Resistant ABS Plastic, Polycarbonate,
Polypropylene, Aluminium, Stainless Steel
Enviromental IP55
Pole Mounting Diameter 15-86 mm
Temperature -30°C to +55°C (-22°F to +131°F)
Wind Survival 160 km/hour
Mechanical Tilt ± 25°
Weight
2 Kg / 4.4 lbs – single unit
2.8 Kg / 6.2 lbs – single unit incl. package
15.4 Kg / 34 lbs – carton (5 units)
Single Unit Retail Box: 31 × 32 × 24 cm
5 Units Carton Box: 32 × 35 × 119 cm
