ADAPTOR FOR ROCKET® 5AC PRISM
Product ID: TP-ADAP-R5AC-PRISM
TwistPort™ Adaptor
for Rocket 5AC Prism
Antenna Connection TwistPort – Quick Locking Waveguide Port
Radio Connection 2x Slide-On RP-SMA and2x RP-SMA for GPS
Materials Insert – Aluminium Alloy
Adaptor – UV stabilized and weather resistant ABS plastic
Flame Rating UL 94 HB
Temperature -40°C to +60°C (-40°F to +140°F)
Wind Survival 160 km/h
Weight
0.36 Kg /0.8 lbs – single unit
0.46 Kg /1 lbs – single unit incl. package
10 Kg /22 lbs – carton (20 units)
Single Unit Retail Box: 17 × 13 × 10 cm
20 Units Carton Box: 51.5 × 26.5
